I needed to install a CB for some group runs. I could not find a location I liked on the forum so I decided on mounting at the headliner. I used a piece of aluminum 3/16” and shaped it to fit the curve from the mirror up the headliner. Mounting with the mirror allows for the mirror break-away to release the CB if needed. The Cobra 19 is light (20 oz.) and inexpensive less than $40. By cutting a hole in the aluminum bracket the size of the raised mounting location for the mirror then using the mirror to trap the bracket (you must shim the mirror mount out the thickness of bracket material) holds bracket tight. I mounted the antenna like the Bandi mount with cable entering at the rubber tube connecting door to body then thru Jack area to and under scuff plates to A pillar then up along windshield to radio. I ran power and PA cables along windshield and down A pillar to fuse block.




·
Registered
Joined
·
286 Posts
Nice mounting job, but that dangling cord would drive me nuts. I'd have to rig up something to contain it. Still, I like the CB's placement.


·
Registered
Joined
·
591 Posts
I mounted mine where the passenger arm rest would go. But I really like the mirror mount. Just not sure if I could live with the dangling cord....:slant:


·
Registered
Joined
·
1,360 Posts
Very nice. I really like the placement. If I hadn't gone with a removeable option, I might have followed your placement. You can already remove the mic when you are not on the trails.


·
Premium Member
Joined
·
1,957 Posts
I needed to install a CB for some group runs. I could not find a location I liked on the forum so I decided on mounting at the headliner. I used a piece of aluminum 3/16” and shaped it to fit the curve from the mirror up the headliner. Mounting with the mirror allows for the mirror break-away to release the CB if needed. The Cobra 19 is light (20 oz.) and inexpensive less than $40. By cutting a hole in the aluminum bracket the size of the raised mounting location for the mirror then using the mirror to trap the bracket (you must shim the mirror mount out the thickness of bracket material) holds bracket tight. I mounted the antenna like the Bandi mount with cable entering at the rubber tube connecting door to body then thru Jack area to and under scuff plates to A pillar then up along windshield to radio. I ran power and PA cables along windshield and down A pillar to fuse block.


I plan on mounting the same on the headliner and now I don't have to cut the headliner to do it. Thanks

Nice mounting job, but that dangling cord would drive me nuts. I'd have to rig up something to contain it. Still, I like the CB's placement.
I don't like the dangling cord either so I'm modifying the Cobra to run the mic cord out the back and it will come out the side of the center console. I'll post pics when I'm done.


·
Registered
Joined
·
1,464 Posts
very clean install...let us know how it stands up to use on the trail


·
Registered
Joined
·
204 Posts
Discussion Starter · #10 ·
very clean install...let us know how it stands up to use on the trail
I have over 36,000 miles on the FJ. Over 20,000 of those with CB installed. Mostly Los Angeles freeways that pound on the suspension, also a few miles running local trails just to give the rig a break. No problems to report.


·
Registered
Joined
·
3,182 Posts
Nice work. Simple and clean.
What would be your opinion about mounting a radar detector to the bottom of the CB? Would there be a weight or visual issue?


·
Registered
Joined
·
4,335 Posts
Great install.


·
Registered
Joined
·
64 Posts
This is the best Idea for a mount Ive seen. Does anyone think that there woulde be an issue using a full size radio? Could the mirrior mount support the weight?


·
Registered
Joined
·
204 Posts
Discussion Starter · #14 ·
The mirror has a break away insert to allow it to separate if needed. This is holding the bracket in place. I think it would hold just find, my kids pull on the mic cord pretty good some times. You could always reinforce the mirror side mount but it would then require more force to break away if needed.


·
Registered
Joined
·
62 Posts
I want to do the exact same thing but I have a big unit...what did you drill the front screws of the bracket into? Did you just guess? or did you locate the crossmember? And what length screw?


·
Registered
Joined
·
204 Posts
Discussion Starter · #17 ·
There are no screws in the bracket on my installation. The bracket is sandwiched between the front cross member and mirror bracket. Looking at my radio today it dawned on me that there might not be enough space between visors for a much larger radio.


·
Registered
Joined
·
134 Posts
I like that! Good Job Bro!


·
Registered
Joined
·
35 Posts
I mounted mine the same way, in fact I have the same radio. The template is pretty much the mirror mounting plate. Meaning, you use the mirror mounting plate to mark your holes, drill them, and then you can just hold the radio (with the bracket attached to the radio) to the new plate and find where you drill the other holes.

My pic isn't real clear, but I think you can get the idea.
